SMD-01B

Metrology and precision 2-channel Encoder module
- Accurate Encoder Performance
- High resolution 20 µm track period
- 1270 LPI (Lines per Inch) / 50 Lines per mm
- Quadrature output is 5080 LPI / 200 Lines per mm
- Low noise A/B analog and digital Z (index) outputs
- Low distortion Lissajous curve reduces cyclical errors and improves interpolation repeatability and accuracy
- Lower assembly & manufacturing costs
- Proven reliability and long lifetime
- 14-pin HCOB (5.3 × 4.3 × 1.68mm)
- Optimized OEIC and optics design for easier mounting alignment
- High resolution 20 µm track period
- Metrology, CMM
- Laser optical axis control
- Assembly machines
- Measuring instruments
- Precision rotary and linear encoders
- Stages, Actuators
- Robotics
The SMD-01B is a miniature, Optical reflective incremental encoder head module with 2-Channel analog A/B outputs.
SMD-01B 20µ period combined with interpolation circuit can achieve subnanometer resolution. And SMD-01B low-noise low distortion analog output maximize accuracy.
A unique LED receptor provide wider tolerance to misalignment, YAW, external contamination and humidity. This reduces assembly process workload required for a high-precision encoder, and simultaneously supports miniaturization and high accuracy requirements.
Encoding | Imperial | Metric | ||
---|---|---|---|---|
LPI (lines per inch) | Resolution | LPM (lines per mm) | Resolution | |
×1 | 1270 LPI | 0.787 mils | 50 LPM | 20µm |
Quadrature A-B ×4 | 5080 LPI | 0.197 mils | 200 LPM | 5µm |
With external ADC 12-bit Interpolation | 20,807,680 LPI | 0.0000481 mils | 819,200 LPM | 0.0012207µm |
- Sample order and design kits available from stock
- Production orders lead-time 16-18 weeks
- Contact sales@vcamericaelectronics.com to confirm price and delivery
